Plain Weave Stainless Steel Filter Wire Mesh Customized For Gas / Liquid Filtering

  • Plain Weave Stainless Steel Filter Wire Mesh Customized For Gas / Liquid Filtering
  • Plain Weave Stainless Steel Filter Wire Mesh Customized For Gas / Liquid Filtering
Herkunftsort Hengshui, China
Markenname TL
Modellnummer Tl k 06
Min Bestellmenge 5 Rollen
Preis 8-40 per square meter
Verpackung Informationen Innerhalb wasserdichtes Papier außerhalb des Holzkartons
Lieferzeit 14 Arbeitstage
Versorgungsmaterial-Fähigkeit 3000 Rollen pro Monat

Treten Sie mit mir für freie Proben und Kupons in Verbindung.

whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Wenn Sie irgendein Interesse haben, leisten wir 24-stündige Online-Hilfe.

x
Produktdetails
Material Edelstahldraht AISI201, 202, 301, 302, 304, 304L, 321, 316, 316 L Typ Drahtgitter weben
Webenstil Einfaches Gewebe Drahtdurchmesser 0,025 mm-2mm, 0,025 mm-10 mm
Verwendung Filtersieger Demister Pad Breite 0,5-2 m
Länge Angepasst Besonderheit Korrosionsbeständigkeit
Anwendung Luft- und Flüssigkeitsfiltration Lochform irregulär
Hervorheben

stainless steel filter wire mesh

,

customized gas liquid filter mesh

,

plain weave stainless steel mesh
Hinterlass eine Nachricht
Produkt-Beschreibung
Plain Weave Stainless Steel Filter Wire Mesh Customized For Gas / Liquid Filtering
Product Specifications
Attribute Value
Material stainless steel wire AISI201, 202, 301, 302, 304, 304L, 321, 316, 316 L
Type Weave wire mesh
Weave style Plain weave
Wire Diameter 0.025mm-2mm, 0.025mm-10mm
Usage Filter strainers demister pad
Width 0.5-2m
Length Customized
Feature Corrosion Resistance
Application Air & Liquid Filtration
Hole shape irregular
Product Description

Knitted Wire Mesh for Gas and Liquid Filtering (Stainless Steel, Galvanized, Plastic, Stainless Knitted Wire Mesh)

  • Material: stainless steel wire (AISI201,202,301,304,304L,321,316,316L,etc), galvanized wire, red copper wire, nickel wire, PEFT, terylene wire, polythylene wire, etc.
  • Wire scope: 0.1-0.55mm (common wire is 0.2-0.25mm), wire can be single and multi-strand; round and flat.
  • Hole size: mesh can be from 2×3mm, 4×5mm to 12×6mm, other sizes as customers' demands.
  • Surface treatment for filter: Flat and crimped, if wavy should provide crimped width and depth.
  • Filter mesh width: 40mm, 80mm, 100mm, 150mm, 200mm, 300mm, 400mm, 500mm, 600mm.
  • Filter mesh length: 30m, 50m, 100m, others as customers' demands.
Applications
  • Used to make demister mesh
  • As screens/disc for gas-liquid separation, gas water separation, water-oil separation
  • All kinds of filter elements used on engines for cars, tractors
  • Used on other electronic and electrical products
Technical Specifications
Type Mesh quantity and Width Wire diameter (MM) Material Weight (kgs/sqm)
Standard 40-100 0.1X0.4 1Cr18Ni9 1/0.5
Standard 60-180 0.1X0.4 1Cr18Ni9 1/0.5
Standard 140-400 0.1X0.4 1Cr18Ni9 1/0.5
Standard 40-100 0.27 Gal. Lead wire 1/0.7
Standard 40-100 0.1X0.4 Copper wire 1/0.7
Standard 40-100 0.25 polyamide fibre 1/0.7
Standard 40-100 0.2 polyethylene wire 1/0.7
Standard 40-100 0.2 Polypropylene wire 1/0.7
Efficient type1 60-100 0.15 Polypropylene wire 1/0.7
Efficient type1 70-100 0.1X0.3 Stainless steel wire 1/0.6
Efficient type1 80-100 0.1X0.3 Stainless steel wire 1/0.6
Efficient type1 90-150 0.1X0.3 Stainless steel wire 1/0.6
Efficient type1 200-400 0.1X0.3 Stainless steel wire 1/0.6
Efficient type1 60-100 0.1X0.5 polyamide fibre 1/0.6
Efficient type1 80-100 0.1X0.5 polyamide fibre 1/0.6
Efficient type2 20-160 0.1X0.4 Stainless steel wire 1/0.4
Efficient type2 30-150 0.1X0.4 Stainless steel wire 1/0.4
Efficient type2 70-400 0.1X0.4 Stainless steel wire 1/0.4
We can weave the special size for you according to your requirements
Key Features
  • High filtration efficiency
  • High strength and firm structure
  • High temperature resistance
  • Corrosion and rust resistance
  • Acid and alkali resistance
  • Will not scratch or mar
  • Wide range of application
  • Long service life
Plain Weave Stainless Steel Filter Wire Mesh Customized For Gas / Liquid Filtering 0
Qualified products, competitive prices, timely delivery, considerate service, etc.
